1. Engine: well-known brand Guangxi Yuchai turbocharged engine;
2. Traveling device: equipped with new traveling motor and reducer, with long service life;
3. Hydraulic oil pump: imported from the United States, parallel gearbox design, independent oil pump, providing sufficient and reasonable power distribution. The advanced hydraulic system has unique design, simple maintenance and low cost;
4. Power head device; the box is integrally formed, and the dual motors provide greater power, greater torque, more durability, and lower maintenance costs;
5. Drilling rig chassis; professional excavator chassis, classic and durable, load-bearing, wide chain plate width,
Less damage to hard pavement;
6. Lifting force: The designed composite boom is used, which is small in size, long in stroke, double-cylinder lifting force, and large in lifting tonnage of the drilling rig;The boom configured with the rig body is provided with a limit device to protect the safety of the oil cylinder and ensure work safety;
7. Each hydraulic oil pipe is covered with a thick protective sleeve, so that the oil pipe has a longer service life;
8. Dual systems can be installed: 1. Air power system with air compressor 2. Mud pump system with mud pump
|
| The weight(T) | 5.2 | Drillpipe diameter(mm) | Φ76/Φ89 |
| The hole diameter(mm) | 140-254 | Drill pipe length(m) | 1.5m/2.0m/3.0m/6.0m |
| Drilling depth(m) | 180 | Rig lifting force(T) | 12 |
| One-time advance length(m) | 3.3 | Rapid rise speed(m/min) | 20 |
| Walking speed(km/h) | 2.5 | Fast feeding speed(m/min) | 40 |
| Climbing angles(Max.) | 30 | Width of loading(m) | 2.4 |
| Equipped capacitor (kw) | 60 | Hoisting force of winch(T) | ---- |
| Using air pressure(MPA) | 1.7-2.5 | Swing torque(N.m) | 3200-4600 |
| Air consumption(m³/min) | 17-31 | Dimension(mm) | 4000×1630×2250 |
| Swing speed (rpm) | 45-70 | Equipped with hammer | Medium and high wind pressure series |
| The penetration efficiency(m/h) | 10-35 | High leg stroke(m) | 1.4 |
| The engine brand | Yuchai engine |
