1. Engine: Well-known brand Guangxi Yuchai turbocharged engine or American Cummins brand turbocharged engine
2. Traveling device: equipped with new traveling motor and reducer, with long service life;
3. Hydraulic oil pump: imported from Italy, parallel gearbox design, oil pump separation, provide
4. Sufficient and reasonable power distribution. The advanced hydraulic system has unique design, simple maintenance and low cost;
5. Power head device; the box body is integrally formed, and the dual motors provide greater power, greater torque, more durability, and lower maintenance costs;
6. Drilling rig chassis; (professional drilling rig chassis), classic and durable, load-bearing, wide chain plate width, less damage to hard roads;
7. Lifting force: The designed composite boom is used, which is small in size, long in stroke, double-cylinder lifting force, and large in lifting tonnage of the rig; the boom configured on the rig body is equipped with a limit device to protect the safety of the oil cylinder. ensure work safety;
8. Each hydraulic oil pipe is covered with a thick protective sleeve, which makes the oil pipe have a longer service life;
9. The independent heat dissipation dual system adopts hydraulic oil temperature cooling and is equipped with traditional air cooling. long engine life
10. Dual system: 1. Air power system with air compressor 2. Mud pump system with mud pump
Product Paratemer
| The weight(T) | 9.5 | Drill pipe diameter(mm) | φ102/Φ108/Φ114 |
| The hole diameter(mm) | 140-350 | Drill pipe length(m) | 1.5m/2.0m/3.0m/6.0m |
| Drilling depth(m) | 500 | Rig lifting force(T) | 26 |
| One-time advance length(m) | 6.6 | Rapid rise speed(m/min) | 20 |
| Walking speed (km/h) | 2.5 | Fast feeding speed(m/min) | 40 |
| Climbing angles(Max.) | 30 | Width of loading(m) | 2.85 |
| Equipped capacitor (kw) | 118 | Hoisting force of winch(T) | 2 |
| Using air pressure(MPA) | 1.7-3.5 | Swing torque(N.m) | 7500-10000 |
| Air consumption(m³/min) | 17-42 | Dimension(mm) | 6150×2200×2600 |
| Swing speed(rpm) | 45-130 | Equipped with hammer | Medium and high wind pressure series |
| The penetration efficiency(m/h) | 15-35 | High leg stroke (m) | 1.6 |
| The engine brand | Yuchai engine |
